ZONESTAR 4 Extruders Mixing Color Multi Color Large Size FDM 3D Printer DIY Kit Z9V5Pro-MK4/MK5/MK6

ZONESTAR 4 Extruders Mixing Color Multi Color Large Size FDM 3D Printer DIY Kit Z9V5Pro-MK4/MK5/MK6

Precio habitual $519.00 USD
Precio habitual $799.00 USD Precio de oferta $519.00 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
OPTION

ATTENTION PLEASE:

If you choosed the option with WiFi module, you need to install the WiFi module to the control board by yourself. About how to install the WiFi module, please refer to the guide at this link:

https://github.com/ZONESTAR3D/Upgrade-kit-guide/tree/main/WiFi

Features:

  • Support multi color 3d printing.
  • Support to print one color 3d model into multi color.
  • Built-in automatic color mixing engine, one-button to realize gradient and random mixing printing (need M4V6 hotend).
  • 95% pre-assembled, fast installation.
  • Ultra silent, working noise is less than 55db.
  • High performance 32-bit control board.
  • 3.5" Full color TFT-LCD screen.
  • Equiped 4 Titan extruders, ability to print 1~ 4 colors 3D prints ( Print more color with M4V6 hotend).
  • Auto resume printing after powe failure.
  • Bed auto leveling.
  • Filament run out detect.
  • Auto power off after printed.
  • Mutil language menu (EN/ES/PT/FR/RU).
  • Open source firmware.

Specifications:

  • Maximus Printing Size: 300*300*400mm
  • Standard Nozzle Diameter: 0.4MM
  • Layer Thickness: 0.1~0.36MM
  • Positioning Accuracy(X&y): Z:0.25um X/Y:0.012mm
  • Extruder Number: 4
  • Hotend type: 4-IN-1-OUT non-mix color hotend
  • Printing Speed: 20-100mm/s
  • LCD Screen: 480x272 dot TFT-LCD
  • Power of heatbed: 24V 350W
  • Recommended Host App: Cura / Repetier-Host
  • Operating System: Windows/mac
  • Date Import Format*: gcode/STL/AML/OBJ,etc.
  • Menu Language: English/France/Russian/Spanish/Portuguese.
  • AC Power Supply: 110V/220V,50/60HZ
  • Printing Material Support: PLA/PLA+/PVA/PETG,etc.
  • Product Size: 56*56*56cm / 22*22*22in
  • Product Weight: 16kg / 35lbs
  • Package Size: 62*59*21cm / 24.4*23.2*8.3in
  • Package Weight: 17.2KG/38lbs

* About the different between M4 and E4 hotend, please refer to here.

User guide:

Z9V5Pro with E4 Hotend:

https://github.com/ZONESTAR3D/Z9/tree/main/Z9V5/Z9V5-MK4

Z9V5Pro with M4 Hotend:

https://github.com/ZONESTAR3D/Z9/tree/main/Z9V5/Z9V5-MK5
